技术参数
AC适配器:
14.5 x 14.5 x 7.7 in / 14.82 lb
环境工作温度:
10 to 40 C / 50 to 104 F
焊丝直径:
0.4-1.8 mm / 0.02-0.07 in
输入保险丝:
1A (230V), 2A (120V and 100V)
速度:
30 mm/s (max) /1.2 in (max)
温度选择:
90-450 C / 190-840 F
导线长度:
1 - 60 mm / 0.04 - 2.36 in
Selectable Temperature:
90 to 450 C / 190 to 840 F
Operating modes:
Continuous / Discontinuous
Voltage (AC):
Ref. AL-1A - 120 V
Package:
368 x 368 x 195 mm / 6.72 kg
PIN protection:
Keep station parameters protected against unauthorized access.
Sleep and Hibernation mode:
These modes lower soldering tip temperature when the tool rests in the stand in order to avoid oxidation and extending tip life.
Control Unit:
195 x 200 x 240 mm / 5.81 kg
Solder wire length:
1 to 60 mm / 0.04 to 2.36 in
Solder wire speed:
0.5 to 30 mm/s / 0.02 to 1.2 in/s
Wire diameter:
0.4 to 1.8 mm / 0.02 to 0.07 in
Max/Min temperature and solder wire length/speed::
Limits the ranges of temperature, solder wire feeding length and speed in which the operator is allowed to work.
